מפצל תמונה Kramer TP-410 עם כניסת VGA/HD,CAT 5 ו-RS-232 ו-10 יציאות (CAT 5 (TP ו-1 יציאות VGA/HD.

מאפיינים ושידרוגים:

מחיר ₪ 6,870 ILS 2027-10-11 In stock KRAMER ELECTRONICS TP-410 TP-410

קנה עכשיו הוסף לסל

INPUTS:	1 UXGA on a 15−pin HD connector, 1 unbalanced stereo audio on a 3.5mm mini jack, 1 S/PDIF on an RCA connector, 1 twisted pair on an RJ−45 connector.
OUTPUTS:	10 twisted pairs on RJ−45 connectors, 1 UXGA on 15−pin HD connectors, 1 unbalanced stereo audio 3.5mm mini jacks, 1 S/PDIF on RCA connectors.
CONTROL PORTS:	RS−232 3−pin terminal block (data and control), RS−485 3−pin terminal block (data and control), RJ−45 Ethernet (data and control).
RESOLUTION:	Up to WUXGA (1920 x 1200) and 2k.
MAX. OUTPUT LEVEL:	Video: 1.6Vpp, Audio: 2.3Vpp.
CONTROLS:	RS−232/RS−485/Ethernet program control, source control from front panel, TP−IN level and equalization from rear panel.
SERIAL BAUD RATE:	Up to 19200 bps.
SERIAL MODE:	Full−duplex.
BANDWIDTH:	AUDIO: 20Hz to 20kHz @0.5dB.
S/N RATIO:	Audio: <−80dB.
TOTAL GAIN:	Audio: 0dB.
COUPLING:	Audio: AC.
AUDIO THD + NOISE:	<0.03%.
OPERATING TEMPERATURE:	0° to +40°C (32° to 104°F).
STORAGE TEMPERATURE:	−40° to +70°C (−40° to 158°F).
HUMIDITY:	10% to 90%, RHL non−condensing.
POWER CONSUMPTION:	100−240V AC, 16VA.
SHIPPING DIMENSIONS:	55.00cm x 27.60cm x 10.70cm (21.65" x 10.87" x 4.21" ) W, D, H
SHIPPING WEIGHT:	2.5kg (5.5lbs) approx.
INCLUDED ACCESSORIES:	Power cord, Windows® based control software, rack “ears”.
