מפצל תמונה Kramer VM-30CA עם כניסת YUV אחת ל-3 יציאות YUV.(משולב אודיו סטריאו)

מאפיינים ושידרוגים:

מחיר ₪ 1,913 ILS 10/7/2027 In stock KRAMER ELECTRONICS VM-30CA VM-30CA

קנה עכשיו הוסף לסל

INPUTS:	1 component video (Y, Pb/Cb, Pr/Cr), 1Vpp, 0.7Vpp, 0.7Vpp/75Ω on RCA connectors; 1 S/PDIF, 75Ω on an RCA connector; 1 unbalanced stereo audio, +4dBu (nominal)/50kΩ on 3.5mm mini jacks.
OUTPUTS:	3 component video (Y, Pb/Cb, Pr/Cr), 1Vpp/0.7Vpp, 0.7Vpp/75Ω on RCA connectors; 3 S/PDIF, 75Ω on RCA connectors; 3 unbalanced stereo audio +4dBu (nominal)/150Ω on 3.5mm mini jacks.
MAX. OUTPUT LEVEL:	Video: 2.3Vpp; Audio: 1.8Vpp (S/PDIF); 25dBu (analog).
BANDWIDTH (-3DB):	Video: 400MHz, fully loaded; Audio: >100kHz.
DIFF. GAIN:	0.03%.
DIFF. PHASE:	0.03Deg.
K-FACTOR:	<0.05%.
S/N RATIO:	Video: 74dB; Audio: 87dB (analog).
CONTROLS:	Video level: –4.1dB to +6.4dB; Audio level: –70dB to +6.2dB; EQ.: 0dB to +6.3dB.
COUPLING:	Video: DC; Audio: Input: AC; Output: DC.
AUDIO THD + NOISE:	0.065%.
AUDIO 2ND HARMONIC:	0.002%.
POWER CONSUMPTION:	12V DC, 500mA.
SHIPPING DIMENSIONS:	35.10cm x 21.20cm x 7.20cm (13.82" x 8.35" x 2.83" ) W, D, H
SHIPPING WEIGHT:	1.2kg (2.6lbs) approx.
INCLUDED ACCESSORIES:	Power supply.
OPTIONS:	RK−1 19" rack adapter.
