î÷øï Maxell MC-CX301 3100L XGA 1024x768

Optical

Panel Size 3LCD 16mm (0.63")

Resolution XGA (1024x768)

Light Output (Brightness) ANSI Lumens 3100 (Normal), 2542 (Eco), 2077 (Eco-2)

Contrast Ratio 10000:1

Lamp Life (Hours) 5000 (Normal), 8000 (Eco), 10000 (Eco-2)

Lens Built-in

Lens Zoom Digital Zoom x 1.35

Lens Focus Manual Focus

Throw Distance 0.691 - 1.838m

Distance to Width Ratio/ Throw Ratio (:1) 0.6

Diagonal Display Size 60 -150”

Features

Speakers 16w Mono

Digital Keystone Correction Vertical: ±5°

Connections

Digital Input HDMI x 2 (HDCP compliant)

Analogue Input 15 pin Mini D-Sub x 2, RCA Jack x 1

Video Output 15 pin Mini D-Sub x 1 (shared with analog computer input)

Audio Input 3.5mm Stereo Mini Jack x 1, RCA Jack (L/R) x 1

Audio Output 3.5mm Stereo Mini Jack x 1

RS-232C Control 1 x 9-pin D-Sub

Wireless LAN USB-WL-11N wireless adaptor (optional)

Wired LAN RJ45 Connector x 1

USB Type A USB Type A x 2 (PC less Presentation or Wireless adapter)

USB Type B USB type B x 1 (USB display, or USB mouse control)

Power

Power Supply AC 100V – 120V / AC 220V – 240V (50/60Hz)

Operating Power Consumption 320W

Standby Power Consumption Less than 0.35W

Physical

Weight 3.6Kg

Dimensions (W x H x D) (Without feet) 345 x 85 x 303mm

Noise 36dB (Normal) , 29dB (Eco)

Filter Life (Hours) 4000

Compatibility

Computer IBM Compatible VGA, SVGA, XGA, WXGA/WXGA+/SXGA/SXGA+/UXGA (compressed), MAC16"

Video 525i (480i), 525p (480p), 625i (576i), 1125i (1080i@50/60), 750p (720p@50/60), 1125p (1080p@50/60)

Accessories

Supplied Accessories Power Cable (1.8m) x1, Computer Cable (2m) x1, Lens Cap x1, IR Remote Control Unit x1, AA Batteries x2, Application CD (for network, etc.) x1, CD User Manual x1, Concise User Manual x1, USB Wireless Adapter Cover x1

Optional Accessories USB wireless adaptor USB-WL-11N. Wireless pen tablet TB-1 is optional.

Remote Control HL03035

Replacement Lamp / Filter DT01511
