| Display Technology |
1 x 0.65" DLP® chip, DarkChip3™ |
| Native Resolution |
Ultrawide 1920x720 |
| Brightness1 (Bright Mode) |
3000 centre lumens (2700 ANSI) |
| Contrast |
10,000:1 (1800:1 full on / full off) |
| Lamp Life2 Bright |
20000 (hrs) |
| Lens Options |
Fixed ultra-short throw (UST) lens |
| Throw Ratio 3 |
0.25:1 |
| Zoom Type |
1.0x fixed |
| Lens Shift |
Fixed |
| I/O Connectors |
2 x HDMI (V1.4a with MHL 2.0 on Input 2), 2 x VGA (YPbPr / RGB), Composite, Audio In 3.5mm jack, Audio In RCA, Microphone In, USB Type A, VGA Out (Shared with VGA Input 2), Audio Out 3.5mm jack, RJ45, RS-232, Remote Mouse / Service Port (Mini USB), Interactive 3.5mm jack, |
| Speaker |
10W |
| Audio |
10W |
| Keystone Correction |
±5° Vertical, ±5° Horizontal |
| Weight (kg) |
5.5 |
| Dimensions (W x D x H) (mm) |
383 x 310 x 126mm |
| Aspect Ratio |
16:6 native, 16:10 / 16:9 / 4:3 compatible |
| Projection Screen Size |
120" - 140" (305cm – 356cm) diagonal, 16:6 |
| Projection Distance |
0.72 - 0.84m |
| Projection Lens |
F/2.4; focal length 3.72mm |
| Uniformity |
80% |
| Maximum Resolution |
1920 x 720 |
| Computer Compatibility |
UXGA, SXGA, WXGA, HD, XGA, SVGA, VGA, Mac |
| Video Compatibility |
PAL (B, D, G, H, I, M, N, 576i/p), NTSC (M, 4.43/3.58 MHz, 480i/p), SECAM (B, D, G, K, K1, L) HD (1080i, 720p) |
| 3D Support |
The 3D features of Optoma projectors can only be used with compatible 3D content. Typical applications include use with 3D educational or 3D design and modelling systems. 3D television broadcast systems, (SKY in the UK), Blu-ray 3D™ and 3D games from the Sony® PS3 and Microsoft® Xbox 360 are now supported as part of the HDMI v1.4a specification. |
| 3D Compatibility |
Side-by-Side:1080i50 / 60, 720p50 / 60
Frame-pack: 1080p24, 720p50 / 60
Over-Under: 1080p24, 720p50 / 60 |
| Horizontal Scan Rate |
15.3 - 91.1kHz |
| Vertical Scan Rate |
24 - 85Hz (120Hz for 3D) |
| Displayable Colours |
1.07 billion |
| Noise Level (Eco mode) |
32dB |
| Noise Level |
32dB |
| Power Supply |
100 - 240V, 50 - 60Hz |
| Power Consumption |
335W Bright mode, 225W Eco mode, <0.5W standby |
| Lamp Type |
Laser phosphor |
| Operating Conditions |
5°C - 40°C, 90% max humidity, 3000m max altitude |
| Operating Temperature |
5°C - 40°C |
| Security |
Security bar, Kensington lock, Password protection |
| On Screen Display |
17 languages: English, German, French, Italian, Spanish, Polish, Swedish, Dutch, Portuguese, Japanese, Traditional Chinese, Simple Chinese, Korean, Russian, Arabic, Norwegian, Turkish |
| Remote Control |
Yes |
| Standard Accessories |
AC mains power cable, VGA cable, USB cable, Interactive cable, Remote control handset, 'AAA' batteries, Interactive module, 2x Interactive pens, Quick start guide, User manual (CD) |
| Optional Accessories |
Wall mounting bracket, WPS Wireless adaptor |
| Optional Wireless |
Yes |
| Max Brightness |
3000 lumens |
| 360’ Operation |
No - Downward projection only |
| Portrait Mode |
Yes |
| Warranty |
3 Years |
| RoHS |
Compliant |
| Video |
RCA |
| Projection method |
Front, rear, ceiling mount, table top, downward, portrait |
| VGA\USB In |
VGA 15-pin D-sub |
| Features |
UWHD resolution, ultra-short throw, laser-phosphor light engine, TouchBeam interactive technology |
