Display System
Display System 3 LCD system
Display device
Size of effective display area 0.75” (19 mm) x 3 BrightEra LCD Panel, Aspect ratio: 16:10
Number of pixels 3,072,000 (1280x800 x 3) pixels
Projection lens
Focus Manual
Zoom - Powered/Manual Manual
Zoom - Ratio Approx. x 1.6
Throw Ratio 1.10:1 to 1.79:1
Light source
Type Ultra high pressure mercury lamp
Wattage 225 W type
Recommended lamp replacement time *1
Lamp mode: High 4000 H
Lamp mode: Standard 6000 H
Lamp mode: Low 10000 H
Filter cleaning / replacement cycle (Max.)
Filter cleaning / replacement cycle (Max.) 10,000 H
Screen size
Screen size 30" to 300"(0.76 m to 7.62 m) (measured diagonally)
Light output
Lamp mode: High 4200 lm
Lamp mode: *2 3200 lm
Lamp mode: Low *2 2500 lm
Color light output
Lamp mode: High 4200 lm
Lamp mode: Standard *2 3200 lm
Lamp mode: Low *2 2500 lm
Contrast ratio (full white / full black) *3
Contrast ratio (full white / full black) 3700:1
Speaker
Speaker 16 W (monaural)
Displayable scanning frequency
Horizontal 15 kHz to 92 kHz
Vertical 48 Hz to 92 Hz
Display resolution
Computer signal input Maiximum display resolution: 1600 x 1200 dots *4
Video signal input NTSC, PAL, SECAM, 480/60i, 576/50i, 480/60p, 575/50p, 720/60p, 720/50p, 1080/60i, 1080/50i, 1080/60p, 1080/50p
Color system
Color system NTSC3.58, PAL, SECAM, NTSC4.43, PAL-M, PAL-N, PAL-60
Keystone correction (Max.) *4
Vertical +/-20 degrees
OSD languages
OSD languages 24-languages (English, French, German, Italian, Spanish, Portuguese, Japanese, Simplified Chinese, Traditional Chinese, Korean, Russian, Dutch, Norwegian, Swedish, Thai, Arabic ,Turkish, Polish, Vietnamese, Farsi, Finnish, Indonesian, Hungary, Greek)
INPUT OUTPUT (Computer/Video/Control)
INPUT A RGB / Y PB PR input connector: Mini D-sub 15-pin (female)
Audio input connector: Stereo mini jack
INPUT B RGB input connector: Mini D-sub 15-pin (female)
Audio input connector: Stereo mini jack
INPUT C HDMI input connector: HDMI 19-pin, HDCP support
Audio input connector: HDMI audio support
INPUT D HDMI input connector: HDMI 19-pin, HDCP support
Audio input connector: HDMI audio support
S VIDEO IN S Video input connector: Mini DIN 4-pin
VIDEO IN Video input connector: Phono jack
OUTPUT MONITOR output connector *5: Mini D-sub 15-pin (female)
Audio output connector *6: Stereo mini
REMOTE RS-232C connector: D-sub 9-pin (male)
LAN RJ-45, 10BASE-T/100BASE-TX
USB Type-A
USB Type-B
MICROPHONE IN Microphone input: Mini Jack
Acoustic noise *5
Lamp mode: Low 29 dB
Operating temperature / Operating humidity
Operating temperature / Operating humidity 0°C to 40°C (32°F to 104°F) / 20-80% (no condensation)
Storage temperature / Storage humidity
Storage temperature / Storage humidity -10 °C to +60°C (-4°F to +140°F) / 20% to 80% (no condensation)
Power requirements
Power requirements AC 100 V to 240 V, 3.4 A to 1.5 A, 50 Hz / 60 Hz
Power consumption
AC 100 V to 120 V Lamp mode: High: 334 W
AC 220 V to 240 V Lamp mode: High: 322 W
Power Consumption (Standby Mode)
AC 100 V to 120 V 0.5 W (when “Standby mode” is set to “Low”)
AC 220 V to 240 V 0.5 W (when “Standby mode” is set to “Low”)
Power Consumption (Networked Standby Mode)
AC 100 V to 120 V 5.3 W (LAN)
5.7 W (optional WLAN module)
6.0 W (All Terminals and Networks Connected) (when "Standby Mode" is set to "Standard")
AC 220 V to 240 V 5.5 W (LAN)
6.0 W (optional WLAN module)
6.3 W (All Terminals and Networks Connected) (when "Standby Mode" is set to "Standard")
Standby Mode/Network Standby Mode Activated
Standby Mode/Network Standby Mode Activated Approx. 10 Minutes
Wireless Network(s) On/Off Switch
Wireless Network(s) On/Off Switch 1) Press the MENU button, then select [Connection/Power]
2) [WLAN Settings]
3) [WLAN Connection]
4) Select On or Off
Heat dissipation
AC 100 V to 120 V 1139 BTU/h
AC 220 V to 240 V 1099 BTU/h
Dimensions (W x H x D)
Dimensions (W x H x D) (without protrusions) Aprox. 365 x 96.2 x 252 mm (14 3/8 X3 25/32 X9 29/32 ” )
Mass
Mass Approx. 4.1 kg (9 lb)
Supplied accessories
Remote commander RM-PJ8
Optional Accessories
Optional Lamp LMP-E221
Wireless LAN module IFU-WLM3
