Optical
Display Device
3 LCD 0.63" aspect ratio 4:3
Resolution
XGA (1024 x 768)
Brightness
5800 ANSI lumens (Normal Mode) / 4060 ANSI lumens (Eco Mode)
Contrast Ratio
10,000:1
Lens
Manual focus, manual zoom x1.6
Lens Shift
Manual (V:0-50%,H:±5%)
Lamp Wattage
300W
Diagonal Display Size
30"~300" (76cm~762cm)
Lamp Life
4000 hours (Normal Mode)/6000 hours (Eco Mode)*
Distance To Width Ratio
1.4~2.3
Focus Distance
0.8m~8.6m (Wide) / 1.4m~14.0m (Tele)
Compatibility
Computer Compatibility
VGA, SVGA, XGA, WXGA, WXGA+, SXGA, SXGA+, WSXGA+, UXGA, WUXGA, MAC 16"
Composite/S-Video
NTSC, PAL, SECAM, PAL-M, PAL-N, NTSC4.43
Component Video/HDMI
525i(480i), 525p(480p), 625i(576i), 1125i(1080i@50/60), 750p(720p@50/60), 1125p(1080p@50/60)
Features
Picture Adjustments
Perfect Fit & V/H Keystone
Advanced Features
Accentualizer technology, DICOM simulation, Instant stack, HDCR (High Dynamic Contrast Range), Edge blending, Warping
Network
Projector control, Network presentation, Wireless capability, AMX Device Discovery, Crestron RoomView® compatible
OSD Languages
English, French, German, Spanish, Italian, Norwegian, Dutch, Portuguese, Japanese, Traditional Chinese, Simplified Chinese, Korean, Swedish, Russian, Finnish, Polish, Turkish, Persian, Arabian, Thai, Danish, Czech, Hungarian, Romanian, Slovenian, Croatian, Lithuanian, Estonian, Latvian, Greek, Brasileiro, Indonesian, Vietnamese
Security Systems
Password/My Screen Password, PIN lock, Key lock
Keystone Correction
Vertical 10:0 shift, Normal at + 12.5° ~ 7.8° projection angle
Digital Keystone Correction
Perfect Fit & V/H Keystone (Horizontal: ±30 degrees, Vertical: ±30 degrees)
Connections
Digital Input
2 x HDMI (HDCP compatible)
Computer Input
1 x 15-pin Mini-D-sub
Monitor Output
1 x D-sub 15-pin connector, 1 x HDMI
Video Input
RCA connector x 1
Control
1 x D-sub 9-pin
USB T Ype A
1
Wired Network
1 x RJ-45
Wireless Network
IEEE802.11b/g/n (Optional USB wireless adaptor is required)
Wired Remote Control Port
1 x 3.5mm mono mini connector
Power
Power Requirements
AC 100V-120V (50/60Hz) 4.4A, AC 220V-240V (50/60Hz) 2.2A
Physical
Dimensions (W X H X D)
460 x 138 x 334mm (excluding feet and extrusions)
Operating Temperature
0 -40°C (Normal mode) / 0-45°C (Eco Mode)
Weight
6.9 Kg
Noise Level
38dB (Normal Mode) / 29dB (Eco Mode)
Air Filter
10,000 hours
