מקרן EIKI EK-308U 6000L WUXGA 1920x1200

Model EK-308U
EAN  4571194679441
Display Type 0.64" 3LCD
Resolution WUXGA (1,920 x 1200)
Aspect Ratio 16:10
Brightness (ANSI) 6,000 lm*
Contrast Ratio 10,000:1 (with IRIS on & ECO mode)
Projection Light Source 300W x 1
Light Source Life 4,000 / 3,000 hours (Eco / Normal)
Image Diagonal 30" - 300"
Lens Lens Spec. (F-number / Focal Length) F = 1.6 - 1.9, f = 15.31 - 24.64mm
Zoom / Focus Adjustment Manual
Zoom Ratio x 1.6
Throw Ratio 1.07-1.75 : 1
Throw Distance (Wide - Tele) 0.68 - 11.43 m
Lens Shift V:±45% ,H:±9%
Keystone Correction V:±30°, H:±15°, Corner Keystone V:±30°, H:±15°, Corner Keystone, Curved Correction
Projection Elevation Adjustment Up to 10 degrees
Scanning Frequency Auto : H Sync. 15 - 100 kHz, V Sync. 48 - 85 Hz
Dot Clock 150MHz
Input Signals - Computer WUXGA (1920 x 1200) - VGA ( 640 x 480)
Input Singals - Video 480 i/p, 576 i/p, 720p, 1080 i/p
Terminal SDI IN -
HDBaseT -
HDMI IN HDMI x 2 (1 HDMI supports MHL)
Display Port -
DVI-D IN -
VGA IN D-sub 15 x 1 (Shared with Component / S-Video), D-sub 15 x 1 (Shared with Monitor Out)
RGBHV -
YPbPr (Component) IN D-sub 15 x 1 (Share with VGA 1, S-Video )
Video (Composite) IN RCA x 1
S-Video IN D-sub 15 x 1 (Shared with VGA 1 / Component)
LAN RJ45 x 1
Monitor Out D-sub 15 x 1 (Share with VGA 2 )
Audio in RCA x 2 (L / R) x 1, 3.5mm stereo mini jack x 1
Audio out 3.5mm stereo mini jack x 1
USB USB Type A x 1 (Memory Viewer) , Micro USB x 1 (USB Display / Service)
3D SYNC -
RS232C D-sub 9 x 1
Remote Control -
Others -
Built-in Speaker Mono 10.0 W x 1
Fan Noise 35.9dB / 40.9dB (Eco / Normal)
Dimensions (W x H x D) 395 x 128 x 318 mm
Weight 4.5 kg
Power Requirements AC 100 - 240 V , 50 / 60 Hz
Power Consumption 420W / < 0.5 W / < 2.0 W (Normal / Stadby / LAN Control Standby)
Thermal Dissipation 1,433BTU
Standard Accessories AC Power Cord, HDMI cable, Remote Control (with AAA Batteries x 2), Quick Start Guide, Safety Information AC Power Cord, VGA cable, Remote Control (with AAA Batteries x 2), Quick Start Guide, Safety Information
Note * : Center Lumen
*2:LAN control: Crestron / AMX / PJ Link)
