| Display Technology |
DLP™ Technology by Texas Instruments, 0.67” WUXGA, DC3,Type A chip |
| Native Resolution |
WUXGA 1920 x 1200 |
| Brightness1 (Bright Mode) |
7500 Centre Lumens using Bright colour wheel (Dual Lamp) / 7000 ANSI Lumens |
| Contrast |
5000:1 |
| Lamp Life2 Eco/Bright |
2500/2000 (hrs) |
| Lens Options |
WT1 "Short throw 0.78 (Fixed)"
WT2 "Wide 1.22~1.47 (1.2x zoom)"
ST0 "Standard 1.45~1.95 (1.33x zoom)"
ST1 "High quality” 1.45~1.95 (1.33x zoom)"
TZ1 "Long 1.93~3.71 (1.9x zoom)"
TZ2 "Extra long 3.68~7.04 (1.9x zoom)" |
| Throw Ratio 3 |
0.77 ~ 6.98 "Lens dependent" |
| Zoom Type |
Motorised |
| Lens Shift |
Motorised lens shift, focus and zoom (+60% -20% V, ±10% H) |
| I/O Connectors |
2 x HDMI, 5BNC, Component Video, 2 x VGA (YPbPr/RGB), S-Video, Composite, VGA Out, RJ45, RS232, +12v Tigger, Wired remote |
| Keystone Correction |
Horizontal +20° / Vertical ±20° |
| Weight (kg) |
24Kg (without lens) |
| Dimensions (W x D x H) (mm) |
439 x 549 x 235 |
| Aspect Ratio |
16:10 Native, 16:9/4:3 Compatible |
| Projection Screen Size |
Dependent upon lens |
| Projection Distance |
Dependent upon lens |
| Projection Lens |
5 x lens Options "no lens supplied as standard" |
| Uniformity |
95% (centre) |
| Maximum Resolution |
Native WUXGA (1920 x 1200) |
| Computer Compatibility |
WUXGA, HD, UXGA, WXGA, SXGA+, SXGA, XGA, SVGA, VGA Resized, VESA, PC and Macintosh Compatible |
| Video Compatibility |
PAL (625/576i/p), SECAM, NTSC (525/480i/p), HDTV (720p, 1080i/1080p) |
| Horizontal Scan Rate |
15kHz to 100kHz |
| Vertical Scan Rate |
25Hz to 85Hz |
| Displayable Colours |
16.7 Million |
| Noise Level (Eco mode) |
39dB |
| Power Supply |
100 – 240V AC @ 50 – 60Hz |
| Power Consumption |
970W BRIGHT Mode <0.5W Standby Mode, 730W Eco mode <0.5W Standby Mode |
| Lamp Type |
350W x 2 |
| Operating Conditions |
5 ~ 40˚C, max. humidity 85%, max. altitude 3000m |
| Operating Temperature |
0 ~ 750m, 5 ~ 40˚C,
750m ~ 1500m, 5 ~ 35˚C,
1500m ~ 3000m, 5 ~ 30˚C, |
| Heat Dissipation |
3416 BTU/hr |
| Security |
4-digit PIN code, Kensington Lock port, 2x M8 Safety Mounting Points (Eye Bolts supplied) |
| On Screen Display |
18 Languages: English, German, French, Italian, Spanish, Portuguese, Polish, Dutch, Russian, Finnish, Swedish,Greek, Norwegian/Danish, Hungarian, Czech |
| Remote Control |
Infra-red remote control, Multiple IR code sets for controlling multiple units, Wired connection sup |
| Standard Accessories |
VGA cable, AC power cord, Infra-red remote control, Batteries x 2, User manual CD, Quick start card, WEEE card, Warranty card |
| Optional Accessories |
Video colour wheel 6 Segment RGBCYM (Part No: SP.8JN07GC01) |
| Optional Wireless |
No |
| 360’ Operation |
Yes (around horizontal axis) |
| Portrait Mode |
Not supported |
| Colour Wheel |
Bright wheel 6 Segment RGBCYW (Standard)
Video wheel 6 Segment RGBCYM (Optional) Part No: SP.8JN07GC01 |
