| Power consumption |
100-120 V: 310 W, 220-240 V AC: 290 W
(0.4 W when Standby mode set to ECO*1,
5 W when Standby mode set to Network,
14 W when Standby mode set to Normal) |
| LCD panel |
Panel size |
16.0 mm (0.63 in) diagonal (4:3 aspect ratio) |
| Display method |
Transparent LCD panel (x 3, R/G/B) |
| Pixels |
786,432 (1024 x 768) pixels |
| Lens |
Manual zoom (1.6x) (throw ratio: 1.2-1.9:1), manual focus, F 1.60-2.12, f 15.30-24.64 mm |
| Screen size (diagonal) |
0.76-7.62 m (30-300 in), 4:3 aspect ratio |
| Resolution |
1,024 x 768 pixels*3 |
| Brightness*2 |
4,500 lm (input signals: PC, lamp power: Normal, picture mode: Dynamic) |
| Lamp |
Lamp |
230 W x 1 lamp (240 W driven) |
| Lamp replacement cycle |
5,000 h/7,000 h (lamp power: Normal/Eco) |
| Center-to-corner uniformity*2 |
85% |
| Contrast*2 |
10,000:1 (Full On/Off) (input signals: PC, lamp power: Normal, picture mode: Dynamic, IRIS: On) |
| Scanning frequency |
HDMI IN |
fH: 15-80 kHz, fV: 50-85 Hz, dot clock: 162 MHz or lower |
| RGB |
fH: 15-100 kHz, fV: 50-100 Hz, dot clock: 162 MHz or lower
(Signals exceeding the dot clock rate of 140 MHz are downsampled.) |
| YPBPR(YCBCR) |
fH: 15.75 kHz, fV: 59.94 Hz [525i (480i)]
fH: 31.50 kHz, fV: 60 Hz [525p (480p)]
fH: 45.00 kHz, fV: 60 Hz [750p (720)/60p]
fH: 33.75 kHz, fV: 60 Hz [1125 (1080)/60i]
fH: 28.13 kHz, fV: 25 Hz [1125 (1080)/25p]
fH: 27.00 kHz, fV: 48 Hz [1125 (1080)/24sF]
fH: 67.50 kHz, fV: 60 Hz [1125 (1080)/60p]
fH: 15.63 kHz, fV: 50 Hz [625i (576i)]
fH: 31.25 kHz, fV: 50 Hz [625p (576p)]
fH: 37.50 kHz, fV: 50 Hz [750p (720)/50p]
fH: 28.13 kHz, fV: 50 Hz [1125 (1080)/50i]
fH: 27.00 kHz, fV: 24 Hz [1125 (1080)/24p]
fH: 33.75 kHz, fV: 30 Hz [1125 (1080)/30p]
fH: 56.25 kHz, fV: 50 Hz [1125 (1080)/50p] |
| Video/S-Video |
fH: 15.75 kHz, fV: 60 Hz [NTSC/NTSC4.43/PAL-M/PAL60],
fH: 15.63 kHz, fV: 50 Hz [PAL/SECAM/PAL-N] |
| Optical axis shift |
9:1 (fixed) |
| Keystone correction range |
Vertical |
±40 ° (±30 ° when using Easy Setting)
(maximum value of XGA input) |
| Horizontal |
±30 ° (±20 ° when using Easy Setting)
(maximum value of XGA input) |
| Installation |
Ceiling/floor, front/rear |
| Terminals |
HDMI IN |
HDMI 19-pin x 1 (compatible with HDCP, Deep Color)
480i, 480p, 576i, 576p, 720/60p, 720/50p, 1080/60i, 1080/50i,
1080/60p, 1080/50p, 1080/30p, 1080/25p, 1080/24p, 1080/24sF,
VGA (640 x 480)-WUXGA (1,920 x 1,200),
audio signal: linear PCM (sampling frequencies: 48 kHz, 44.1 kHz, 32 kHz) |
| COMPUTER 1 IN |
D-sub HD 15-pin (female) x 1 (RGB/YPBPR/YCBCR x 1) |
| COMPUTER 2 IN / MONITOR OUT |
D-sub HD 15-pin (female) x 1 (RGB x 1), (input/output selectable using on-screen menu) |
| VIDEO IN |
Pin jack x 1 (Composite VIDEO) |
| S-VIDEO IN |
Mini DIN 4-pin x 1 (S-VIDEO) |
| AUDIO IN 1 |
M3 x 1 (L-R x 1) |
| AUDIO IN 2 (MIC IN) |
M3 x 1 (L-R x 1) for audio input or for microphone connection (variable) |
| AUDIO IN 3 |
Pin jack x 2 (L, R x 1) |
| AUDIO OUT |
M3 x 1 (L-R x 1) for output (variable) |
| LAN |
RJ-45 x 1 (for network connection, 10BASE-T/100BASE-TX, compliant with PJLink™) |
| SERIAL IN |
D-sub 9-pin (female) x 1 for external control (RS-232C compliant) |
| USB-Type A |
for Memory Viewer x 1 |
| USB-Type B |
for USB Display x 1 |
| Built-in speaker |
4.0 cm (1-9/16 in ) round shape x 1, output power: 10.0 W (monaural) |
| Operation noise*2 |
37 dB (lamp power: Normal), 29 dB (lamp power: Eco) |
| Cabinet materials |
Molded plastic (PC) |
| Dimensions (W x H x D) |
352 x 98*4 x 279.4*5 mm (13-27/32 x 3-27/32*4 x 11*5 in) |
| Weight*6 |
Approx. 3.4 kg (7.5 lbs) |
| Operating temperature |
0-40 °C [32-104 °F] (less than 1,400 m [4,593 ft] above sea level, HIGH ALTITUDE MODE: OFF) |
| Operating humidity |
10-80 % (no condensation) |
| Wireless |
Standard |
2.4 GHz: IEEE802.11b/g/n,
5.0 GHz: IEEE802.11a/n |
| Infrastructure mode |
WPA-PSK (TKIP/AES), WPA2-PSK (TKIP/AES),
128 bit/64 bit WEP, WPA-EAP/WPA2-EAP
(PEAP [MS-CHAPv2/GTC],
EAP-FAST [MS-CHAPv2/GTC],
EAP-TTLS [MD5/MS-CHAPv2])128 bit/64 bit |
