מקרן אינטראקטיבי טווח קצר Maxell MC-TW3506 3700L WXGA 1280x800 Interactive Short-Throw

Specifications

Projection Technology 3LCD, 3 chip technology

Resolution WXGA 1280 x 800

White Light Output 3,700 ANSI lumens

Color Light Output 3,700 ANSI lumens

Colors 16.7 million colors

Aspect Ratio Native 16:10, 4:3, 16:9, 14:9 and zoom compatible

Contrast Ratio 20,000 : 1 (using active IRIS)

Throw Ratio (distance : width) 0.2 : 1 from edge of projector to screen 0.3 : 1 from mirror cover to screen

Focus Distance 16" – 27" from mirror cover to screen

Display Size 60" – 100"

Lens f = 4.21 mm, digital zoom x 1.35, powered focus

Lamp Wattage 250W

Expected Lamp Life* Approximately 4,000 hours (standard mode) 6,000 hours (Eco-2 mode)

Expected Filter Life** Approximately 4,000 hours

Speaker Output 16W x 1

Keystone H and V: +/- 5°

Computer VGA, SVGA, WXGA, WXGA+, SXGA, SXGA+, UXGA (compressed), MAC 16"

H-Sync 15 kHz – 106 kHz

V-Sync 50 Hz – 120 Hz

Composite Video NTSC, NTSC4.43, PAL, PAL-M, -N, SECAM

Component Video 480i, 480p, 576i, 576p, 1080i, 1080p

HDMI 480i, 480p, 576i, 576p, 1080i, 1080p, computer signal TMDS clock 27 MHz – 150 MHz

MHL In HDMI connector x 1 (HDCP compliant) shared with HDMI 1 input

Digital Input HDMI x 2 (HDCP compliant) (1 shared with MHL)

HDMI IN HDMI Connector x 2 (HDCP compliant)

Computer Input 1 15-pin mini D-sub x 1 (shared with analog component video input)

Computer Input 2 15-pin mini D-sub x 1 (shared with analog component video input and monitor out)

Computer Monitor Output 15-pin mini D-sub x 1 (shared with computer in 2)

Composite Video Input RCA jack x 1

Component Video Input 15-pin mini D-sub x 2 (shared with computer in 1/2)

Audio Input 3.5mm stereo mini jack x 1, RCA jack (L/R) x 1

Audio Output 3.5 mm stereo mini jack x 1

Network (LAN) Wired RJ-45 port (10 base-T / 100 base-TX)

Network (LAN) Wireless USB-A, IEEE802.11 b/g/n – optional wireless adapter required

USB Type A x 2 (PC-less presentation, wireless adapter) Type B x 1 (USB display or mouse control)

Microphone In 3.5mm mini jack x 1

Control Terminals 9-pin D-sub x 1 (RS-232 control)

Power Supply AC100-120V / AC220-240V, 50/60Hz

Power Consumption 380W/360W

Operating Temperature 32°F – 104° F (0°C – 40°C)

Dimensions (W x D x H) 14.8" x 14.2" x 5.4" (excluding protruding parts)

Weight Approximately 10.1 lbs

Approvals UL 60950-1 / cUL, FCC Part 15 subpart B class B
