Projection System: Epson 3LCD, 3-chip optical engine
Projection Method: Front / Rear / Ceiling mount
Product Color: White and Black
Driving Method: Epson Poly-silicon TFT Active Matrix, 0.74-inch wide panel with MLA
Projected Output: HD, 2D, 3D, 1080p
Pixel Number: 2,073,600 dots (1920 x 1080) x 3
Color Brightness (Color Light Ouput): 2400 lumens1
White Brightness (White Light Output): 2400 lumens1
Aspect Ratio:
- Native 16:9 widescreen
- Compatible with 4:3
Native Resolution: 1080p (1920 x 1080)
Resize: 16:10, 4:3
Lamp Type: E-TORL™ 230 W UHE
Lamp Life:
- ECO mode: Up to 5000 hours2
- Normal mode: Up to 4000 hours2
Throw Ratio Range: 1.34 – 2.87
Size (projected distance): 30" – 300"
Keystone Correction: Vertical: ±30 degrees (Manual)
Contrast Ratio: Up to 600,000:1
Color Reproduction: Up to 1.07 billion colors
Color Processing: 10 bit
Projection Lens
Type: Manual focus / Optical zoom
F-number: 2.3 – 3.6
Focal Length: 22.5 mm – 47.2 mm
Zoom Ratio: 1.0 – 2.1
Lens Shift:
- Vertical: ±96.3
- Horizontal: ±47.1
Lens Cover: Powered, Slide Lens Shutter
Other
Display Performance: 1920 x 1080 native (1080p); HD, 2D, 3D, 2D to 3D conversion
Color Modes:
- 2D: Dynamic, Living room, Natural, THX, Cinema, B&W cinema
- 3D: Dynamic, Cinema, THX
Cinema Filter: Automatically adjusts to color mode;
(On: Natural/THX/Cinema/B&W Cinema;
Off: Dynamic/Living Room/3D Dynamic/3D Cinema/3D THX)
Auto Iris: Automatically adjusts to video source;
Off/On: High-speed or Normal, 2D and 3D mode
Super Resolution: 2D and 3D
Input Signal:
- Composite: NTSC / NTSC4.43 / PAL / M-PAL / N-PAL / PAL60 / SECAM
- Component: 480i / 576i / 480p / 576p / 720p / 1080i / 1080p
- HDMI: TMDS
Terminal Inputs:
- 2 HDMI
- 1 RS-232c
- 1 RCA (composite)
- 3 RCA (component)
- 1 VGA D-sub 15 pin (computer input)
Terminal Outputs:
- Trigger On/Off (3.5 mm stereo jack)
- 12 VDC 200 mA (max.)
Computer Compatibility: PC, Mac®
Operating Temperature: 41° to 95° F (5° to 35° C)
Power Supply Voltage: 100 – 240 VAC ±10% , 50/60 Hz
Power Consumption:
- Lamp on 350 W, Lamp on (Eco) 280 W
Fan Noise: 22 dB – 32 dB
Security: Kensington Security Lock Port
Dimensions
Including feet: 18.34" x 15.5" x 6.2" (W x D x H)
Excluding feet: 18.34" x 15.6" x 5.5" (W x D x H)
Weight: 18.9 lb
Remote Control
Features: Front and rear directional
Operating Angle: Front:
- Right/Left: ± 30 degrees
- Upper/Lower: ± 30 degrees
Rear:
- Right/Left: ± 30 degrees
- Upper/Lower: + 10 – + 70 degrees
Operating Distance: 32 feet (10 meters)
Parental Controls
Power Button Lock: Hinders projector from being turned on without parental supervision
WirelessHD Transmitter
Power Consumption: 11V 1.2A
Operating Altitude: 0 to 7500 ft
Storage Temperature: 14 °F to 140 °F (-10 °C to 60 °C)
Input: HDMI x 5, including 1 MHL enabled
Output: HDMI x 1, Optical Audio x 1, USB Type A x 1 (3D Glasses Charging)
Wireless: FCC Part 15 Subpart C 15.255
Safety: UL 60950-1 2nd edition (cTUVus Mark)
EMC: FCC Part 15B Class B
Wireless HD Type: Beam Forming WirelessHD 1.0b 60 GHz Band (QPSK, 16-QAM, BPSK) 2 ch and 3 ch
Dimensions: 6.9" x 5.0" x 2.0" (W x D x H)
Notes
1Color brightness (color light output) and white brightness (white light output) will vary depending on usage conditions. Color light output measured in accordance with IDMS 15.4; white light output measured in accordance with ISO 21118.
2Lamp life will vary depending upon mode selected, environmental conditions and usage. Lamp brightness decreases over time.
Epson Home Entertainment projectors have up to 3x Brighter Colors than their leading competitive 1-chip DLP Home Entertainment Projectors. Epson 720p projectors are 3x Brighter; Epson 1080p projectors are consistently 2x and up to 3x Brighter. Based on NPD data, July 2011 through June 2012. Color brightness (color light output) measured in accordance with IDMS 15.4. Color brightness will vary depending on usage conditions.
