Specifications of Main Parts:
Lightsource: Type: Laser Diode 41.9 mW (Output)
Life: Up to 20,000 hours (ECO Mode) *2
Screen Size (Projected Distance):
Standard Size:100" diagonal (Wide: 2.83 – Tele: 6.04m)
Brightness:
Colour Light Output:1500 lumens *1
White Light Output:1500 lumens *1
Contrast Ratio:
Contrast Ratio:Absolute Black (Full White 1500 lm / Full Black 0 lm)
Connectivity:
Others:2 HDMI (1 HDMI HDCP2.2), 1 RS-232c, 1 RCA (composite), 3 RCA (component), 1 VGA D-sub 15 pin (computer input), 1 Wired LAN (RJ45, 100 Mbps) for command and control only, 1 USB Type Mini-B (for service and firmware update), 2 3.5mm trigger out mini jack
Power:
Power Consumption:220 – 240V
Laser ON: 442W, Laser ON (ECO): 262W
Standby Communication ON: 2.3W / OFF: 0.34W
Power Supply Voltage:100 – 240V AC ± 10%, 50/60 Hz
Weight:
Weight:18Kg
Fan Noise:
Fan Noise (Normal / Eco):19 dB (4K Enhancement: Off)
Projection Lens:
Type:Powered optical zoom / Powered focus
Focal Length:21.3 mm – 44.7 mm
Zoom Ratio:1 – 2.1
F-number:2.5 – 3.7
Lens Shift:Vertical: 90% max (up and down with horizontal centered)
Horizontal: 40% max (left and right with vertical centered)
Lens Cover:Powered, slide lens shutter
Adjustment Functions:
Aspect Mode:Auto / Normal / Full / Zoom / Anamorphic Wide / Horizontal Squeeze
Frame Interpolation:Off / Low / Normal / High (2D and 3D Mode)
Image Enhancement:
Super Resolution:Off / 1 / 2 / 3 / 4 / 5
Dimension Excluding Feet:
Dimension Excluding Feet (D x W x H):553mm x 550mm × 225mm
Projectors Facets:
4K Enhancement:4K-1 / 4K-2 / 4K-3 / 4K-4 / 4K-5 *3
