Specifications Projector:
Projection System:High-aperture Epson 3-chip, 3LCD technology
Projection Method:Front / rear / ceiling mount
Driving Method:Epson Poly-silicon TFT Active Matrix
Pixel Number:2,304,000 dots (1920 x 1200) x 3
Color Brightness - Color Light Output:12000 lumens1
White Brightness - White Light Output:12000 lumens1
Aspect Ratio:Supports 4:3, 16:9, 16:10
Resolution:1920 x 1200 (WUXGA)
Resize:640 x 480, 800 x 600, 1280 x 1024, 1400 x 1050
Brightness Uniformity:(typical) 90%
Pixel Arrangement:Cross stripe
Throw Ratio Range:(For Standard Lens Only) 1.57 — 2.56
Size - projected distance:50" – 300"
Keystone Correction:
(For Standard Lens)
- Horizontal: ±30 degrees
- Vertical: ±45 degrees
Contrast Ratio:Normal, Dynamic Mode: Up to 15,000:1
Color Processing:10 bit
Color Reproduction:Up to 1 billion colors
Effective Scanning Frequency Range:
Pixel Clock, Horizontal,Vertical:
Pixel Clock
- 13.5 MHz – 162 MHz (up to UXGA 60 Hz)
Horizontal
Vertical
General:
Temperature:32° to 113° F (0° to 45° C)
Weight:42.2 lb without lens
Security:
- Security cable hole
- Lens lock
- Kensington® lock provision,
Projection Lens:
Type:(For Standard Lens) Powered shift/focus / zoom
F-number:(For Standard Lens Only) 1.7 — 2.3
Focal Length:(For Standard Lens Only) 24.0 mm — 38.2 mm
Zoom Ratio:(For Standard Lens Only) Optical zoom 1 — 1.6x
Lens Shift:
(For Standard Lens)
- Vertical: ±67 degrees
- Horizontal: ±30 degrees
Video:
Video Processing:
- Analog: NTSC / NTSC4.43 / PAL / M-PAL / N-PAL / PAL60 / SECAM
- HDMI: 480i / 576i / 480p / 576p / 720p /1080i / 1080p
- DVI-D: 480i / 576i / 480p / 576p / 720p / 1080i / 1080p
Video Standards:
- 3D Y/C separation, 3D noise reduction, mosquito noise reduction
- DCDi — Directional Correlational DeinterlacingMotion-compensated Interlace-Progressive conversion (2:2, 3:2 film detection)
Super Resolution:
- FineFrame Interpolation
- 8:8 Pull-down Processing
- Closed Captioning
Connectivity Projector:
Standard Connectivity:
- Wired: Integrated 100Mbps
- Wireless: Optional — 802.11b/g/n
- Wireless Security: WPA-PSK (TKIP/AES) / WPA2-PSK(TKIP/AES)
Remote Control and Management:
- Epson EasyMP® Monitor
- Network projection
- Multi-projection
- AMX® Device Discovery
- Crestron® Integrated Partner and Crestron RoomView®
- Extron® IP Link and XTP
- PJLink
Projector Details:
Display Performance:
- NTSC: 480 line
- PAL: 576 line
(depends on observation of the multi-burst pattern)
Input Signal:
- NTSC/NTSC4.43/PAL/M-PAL/N-AL/PAL60/SECAM/480i/576i/480p/576p/720p/1080i/1080p
- Pixelworks®:Video Chip 3D Y/C separation, noise reduction motion compensated Interlace-Progressive conversion (2 - 2, 3 - 2 film detection)
Interfaces:
- 3G-SDI x 1
- DVI-D x 1
- HDMI x 1
- HDBaseT x 1
- 5-BNC, VGA x 1
- Audio in: Mini
- Stereo x 3
- Variable audio out: Mini Stereo x 1
- USB connector Type B x 1: For service only
- USB connector Type A x 1: For wireless only
- Monitor out: Mini D-sub 15 pin x 1
- Serial: RS-232c x 1
Speaker:None
Fan Noise:
- Normal mode: 39 dB
- ECO mode: 33 dB
Audio Output:None
Projector Dimensions:
Excluding feet and lens:23.07 x 19.37 x 7.76 (W x D x H)
Including feet - with standard lens:23.07 x 19.37 x 8.31 (W x D x H)
Remote Control:
Features:Power, source search selection, lens shift, zoom, focus, test pattern selection, A/V Mute, freeze, user ID, auto, aspect, color mode, number, page up and down, E-zoom, volume, help, menu, enter, esc and pointer functions
Operating Distance:49 ft
Operating Angle:
Right / Left:
- Front: ±60 degrees
- Rear: ±30 degrees
Upper / Lower:
- Front: ±45 to ±15 degrees
- Rear: ±10 to ±50 degrees
Power:
Power Supply Voltage:100 – 240 V ±10%, 50/60 Hz AC
Power Consumption:
- Normal mode: 955 W
- ECO mode: 597 W
- Communication on: 2.0W standby
- Communication off: 0.23 W standby
