PRODUCT SPECIFICATIONS
Light output*1 5,000 lumens
Technology Laser LCD
LCD panel | Panel size (mm) 16 mm diagonal (16:10 aspect ratio)
LCD panel | Panel size (inch) 0.64 inch diagonal (16:10 aspect ratio)
LCD panel | Display method Transparent LCD panel (x 3, R/G/B)
LCD panel | Drive method Active matrix
LCD panel | Pixels 2,304,000 (1920 x 1200) x 3, total of 6,912,000 pixels
LENS 1.6 x Manual zoom (throw ratio 1.09-1.77 :1), F = 1.60-2.12, f = 15.30-24.64 mm
Light source Laser diode
Screen size (diagonal) (mm) 0.76 - 7.62 m, 16:10 aspect ratio
Screen size (diagonal) (inch) 30-300 in, 16:10 aspect ratio
Center-to-corner uniformity*1 85 %
Contrast*1 3,000,000:1 (all white/all black) (Input signals:PC,LIGHT POWER:NORMAL,PICTURE MODE:DYNAMIC,DAYLIGHT WIEW:OFF,DYNAMIC CONTRAST:[1],AUTO POWER SAVE:OFF)
Resolution 1920 x 1200 pixels
Optical axis shift | Vertical (from center of screen) 0 % - +44 % (Manual)
Optical axis shift | Horizontal (from center of screen) - 20% - +20% (Manual)
Keystone correction range*2 Vertical: ±25°, Horizontal: ±35°
Installation Horizontal/Vertical, free 360-degree installation
Terminals | HDMI 1/2 IN HDMI 19-pin x 2 (Compatible with HDCP, Deep Color, 4K/30p signal input)
Terminals | COMPUTER 1 IN D-sub 15-pin (female) x 1 (RGB/YPBPR/YCBCR)
Terminals | COMPUTER 2 IN / MONITOR OUT D-sub 15-pin (female) x 1 (RGB/YPBPR/YCBCR) (input/output switching)
Terminals | VIDEO IN Pin jack x 1
Terminals | AUDIO 1/2 IN M3 stereo mini-jack x 2
Terminals | AUDIO 3 IN Pin jack (L/R) x 1
Terminals | VARIABLE AUDIO OUT M3 stereo mini-jack x 1
Terminals | SERIAL IN D-sub 9-pin x 1 for computer control (RS-232C compliant)
Terminals | LAN RJ-45 x 1 for network control, 10Base-T, 100Base-TX, compatible with PJLink™ (Class 2)
Terminals | DIGITAL LINK/LAN RJ-45 x 1 for network and DIGITAL LINK connection, HDBase-T™ complian, 100Base-TX, compatible with PJLink™ (Class 2), HDCP, Deep Color, 4K/30p signal input
Terminals | USB CONNECTOR USB connector (Type A) x 1 for Memory Viewer function, power supply (DC5V, maximum 2A*3), optional wireless module AJ-WM50
Power supply AC 100-240 V AC, 50/60 Hz
Power consumption TBD
Built-in Speaker 10 W (monaural)
Operating noise*1 NORMAL: 37dB, QUIET: 29dB
Cabinet materials Molded plastic
Filter Included
Filter cleaning cycle: 20,000 hours (0.08 mg/m3 of particulate matter), 10,000 hours (0.15 mg/m3 of particulate matter)
Dimensions (W x H x D) (mm) 399 x 115 x 348 mm (Not including protruding parts)399 x 133 x 348 mm (With feet at shortest position)
Dimensions (W x H x D) (inch) 15 23/32 x 4 17/32 x 13 11/16 inch (Not including protruding parts)15 23/32 x 5 1/4 x 13 11/16 inch (With feet at shortest position)
Weight (kg)*4 7.2 kg
Weight (lbs.)*4 15.87 lbs.
Operating environment (℃/M) Operating temperature: 0 °C- 45 °C, operating humidity: 20 %-80 % (no condensation)
Operating environment (°F/Feet) Operating temperature: 32 °F -113 °F, operating humidity: 20 %-80 % (no condensation)
Applicable software/application Logo Transfer Software, Multi Monitoring & Control Software, Presenter Light for Windows®, Wireless Projector Apps for iOS/Android™
Note
*1 Measurement, measuring conditions, and method of notation all comply with ISO/IEC 21118: 2012 international standards. Value is average of all products when shipped.
*2 Around this time, light output will have decreased by approximately 50 %. IEC62087: 2008 Broadcast contents, NORMALMode, Dynamic Contrast [2], under conditions with 30 °C (86 °F), 700 m (2,297 ft) above sea level, and 0.15 mg/m3 of particulate matter. Estimated time until light output declines to 50 % varies depending on environment.
*3 On standby, power supply is available with Quick Startup set to ON or Power Management set to Ready.
*4 Average value. May differ depending on the actual unit
