Imaging Device
0.65" DMD x1
Native Resolution
WXGA (1280 x 800)
Brightness
3000 Lumens (Normal) / 2100 Lumens* (Eco)
*Brightness in Eco Mode is only a calculated value, and is not guaranteed as specification.
Digital Keystone (Vertical)
V -18° / +12°
Projection Lens
f=6.9mm, F2.60
Screen Size
70" - 120"
*images with the same aspect ration as the Digital Micromirror Device
Throw Distance
29.1" - 49.9" (0.74 - 1.26m)
Throw Ratio at 100"
0:49:1
Image Mode
Presentation, Standard, sRGB, Movie, User 1, User 2
Wall Correction
Light Yellow, Pink, Light Green, Blue, Blackboard
Mounting
Front Table, Rear Table, Front Ceiling, Rear Ceiling
Tilt Angle
Front: 1 Rear: 1 (the angle of elevation of up to 6°)
Scanning Frequency
V:15.73 ~ 120kHz, H:24 ~ 101.563Hz
Analog PC Input
UXGA / SXGA+ / WXGA+ / FWXGA / WXGA / SXGA / XGA / SVGA / VGA / MAC
Digital PC Input
UXGA / SXGA+ / WXGA+ / FWXGA / WXGA / SXGA / XGA / SVGA / VGA
Analog Video Input
NTSC / PAL / SECAM / NTSC4.43 / PAL-M / PAL-N / PAL-60
Component Input
1080p / 1080i / 720p / 576p / 576i / 480p / 480i
Digital Video Input
1080p / 1080i / 720p / 576p / 480p
Mini Dsub 15 x2
Analog PC / Component video input
HDMI
Digital PC / Digital Video Input
Mini Jack x2
Audio Input x1, Audio Output x1
RJ-45
Network Connection (100BASE-TX / 10BASE-T)
Internal Amplifier
10W, Mono
Type
Super-high Pressure Mercury Lamp
Life
4000 Hours (Normal) / 6000 Hours (Eco)
Power
210W (Normal) / 170W (Eco)
Fan Noise
35db (Normal) / 29dB (Eco)
Power Consumption
330W (Normal) / 275W (Eco)
Standby Power
3.0W / 0.5W
*Standby LAN function is on/off
Power Voltage
AC 100 ~ 240V, 50/60 Hz
Operating Temperature
32°F - 104°F (0°C - 40°C)
Storage Temperature
-4°F - 140°F (-20°C - 60°C)
Dimensions (W x H x D)
W: 11.1"(282 mm), H: 4.64"(117.9mm), D:10.53"(267.5mm) (including protrusion)
