Optical Specifications Detail:
Color Light Output 5100 lumens (lamp mode : high), 4200 lumens (standard)
Light Output 5100 lumens (lamp mode : high), 4200 lumens (standard)
Contrast Ratio 3,000:1
Lamp High-pressure mercury lamp 280 W type
Lamp Life 3000H(lamp mode : High) / 4000H(Standard)
Projection Lens Approx. 1.5x manual zoom / Manual focus
Throw Ratio 1.32 to 1.91:1
Screen Coverage 40" to 300"
Input/Output Specifications Detail:
S-Video In Mini DIN-4pin Audio : RCA x2 (shared with VIDEO IN)
Composite Video In RCA, Audio : RCA x2 (shared with S VIDEO IN)
Analog RGB/Component In Mini D-sub 15-pin (RGB) x1, Mini D-sub 15-pin (RGB/Y Pb Pr) x1 / Audio: Stereo mini jack
Digital In HDMI (Digital RGB/Y Pb Pr, Digital Audio), HDCP Support
Network RJ-45: 10Base-T / 100Base-TX
Monitor Out Mini D-sub 15-pin (from Analog RGB input)
Variable Audio Out Stereo mini jack (variable out)
Remote Control 10W x 1 (monaural)
Electrical Specifications Detail:
Color System NTSC3.58, PAL, SECAM, NTSC4.43, PAL-M, PAL-N, PAL60
Acceptable Computer Signals Maximum display resolution : 1600x1200 dots
Acceptable Video Signals NTSC, PAL, SECAM, 480/60i, 576/50i, 480/60p, 576/50p, 720/60p, 720/50p, 1080/60i, 1080/50i
General Specifications Detail:
Dimensions (W x H x D) W 15 31/32 x H 4 13/16 x D 13"
Weight 12 lbs 6 oz
Power Requirements AC 100V to 240V, 3.9A to 1.7 A, 50 Hz/60 Hz
Power Consumption 390W (AC 100 V-120 V)
Speaker 10W x 1 (monaural)
Other Specifications Detail:
Environmental Notice Lamp in this product contains mercury. Disposal of these materials may be regulated due to environmental considerations. For disposal or recycling information, please contact your local authorities or see www.sony.com/mercury for additional information.
