Resolution Wide XGA (1280 x 800)
Brightness 6000 lumens
Contrast Ratio 2000:1
Uniformity --
No. of Colors Full Color
Aspect Ratio(s) Native - 16:10
Display Type LCD;
Compatibility
Data Signals WXGA (1280 x 800)
Video Signals NTSC3.58, PAL, SECAM, NTSC4.43, PAL-M, PAL-N, PAL60 NTSC, PAL, SECAM, 480/60i, 576/50i, 480/60p, 576/50p, 720/60p, 720/50p, 1080/60i, 1080/50i
H Sync 15kHz to 92kHz
V Sync 48Hz to 92Hz
3D Ready No
Dot Clock --
Connectivity
Inputs / Outputs
BNC, 5 Wire
HD-SDI, BNC
HDMI (High-Definition Multimedia Interface for digital video and digital audio)
Ethernet/RJ45 (Network addressable, RJ45)
VGA (Analog data, mini D-Sub 15-pin)
DVI (DVI (Digital Visual Interface) 29-pin)
RS-232 (Serial)
Call the projector experts at 1-888-248-0675 for more information
Built-in Audio --
Projection Lens Projector Calculator See Sony VPL-FW65 Image Size Calculator »
Lens Powered Zoom (Approx. x 1.6), Powered Focus
Throw Ratio 1.39 - 2.23:1
Keystone Corr. Horizontal and Vertical
Specs: Vertical: +/- 30 degrees Horizontal: +/- 30 degrees
Lens Shift Powered, Vertical: -5%, +60%, Horizontal: +/-32%
Proj. Methods Ceiling, Desktop, Front, Rear
General
Dimensions 18.12" x 6.65" x 20.28" (W x H x D)
Unit Weight 34 lbs.
Operation
Power Supply AC 100 V to 240 V, 5.5 A to 2.3 A, 50 Hz / 60 Hz
Universal Power Supply
Power Consumption 407
Ecomode Yes
(Brightness: 4780 lumens; Lamp life: 4000 hours; Power: 336; Noise: 28 dB)
FCC Class A
Audible Noise 35.0 dB
Lamp High pressure mercury lamp 370 W type
Lamp Life 3000 hours
