Projection Technology 3LCD, 3 chip technology
Resolution XGA 1024 x 768
White Light Output 3,700 ANSI lumens
Color Light Output 3,700 ANSI lumens
Colors 16.7 million colors
Aspect Ratio Native 4:3 and 16:9 / 16:10 / 14:9 / zoom compatible
Contrast Ratio 20,000 : 1 (using active IRIS)
Throw Ratio (distance : width) 1.5 – 1.8 : 1
Focus Distance 33 – 427"
Display Size 30" – 300"
Lens f = 19 – 23 mm, x 1.2 manual zoom and focus
Lamp Wattage 230W
Expected Lamp Life* Approximately 6,000 hours (standard mode) 12,500 hours (eco mode)
Expected Filter Life** Approximately 10,000 hours
Speaker Output 16W
Keystone H and V: +/- 30°
Computer VGA, SVGA, XGA, WXGA, SXGA/SXGA+/HD/UXGA (compressed), Mac 16"
H-Sync 15 kHz – 106 kHz
V-Sync 50 Hz – 120 Hz
Composite Video NTSC, NTSC4.43, PAL, PAL-M, -N, SECAM
Component Video 480i, 480p, 576i, 576p, 720p, 1080i, 1080p
HDMI 480i, 480p, 576i, 576p, 720p, 1080i, 1080p Computer signal TMDS clock 25 MHz – 162 MHz
Digital Input HDMI x 2 (HDCP compliant)
Computer Input 1 15-pin mini D-sub x 1 (shared with analog component video input)
Computer Input 2 15-pin mini D-sub x 1 (shared with analog component video input and monitor out)
Computer Monitor Output 15-pin mini D-sub x 1 (shared with computer in 2 and analog component video input)
Composite Video Input RCA jack x 1
Component Video Input 15-pin mini D-sub x 2 (shared with computer in 1, in 2/monitor out)
Audio Input 3.5mm stereo mini jack x 2, RCA jack (L/R) x 1
Audio Output
3.5mm stereo mini jack x 1
Network (LAN) Wired
RJ-45 port (10 base-T / 100 base-TX)
Network (LAN) Wireless USB-A, IEEE802.11 a/b/g/n/ac – optional wireless adapter required
USB Type A x 1 (PC-less presentation or wireless adapter) Type B x 1 (USB display or USB mouse control)
Control Terminals 9-pin D-sub x 1 (RS-232 control)
Power Supply AC100-120V / AC220-240V, 50/60Hz
Power Consumption 320W / 310W
Operating Temperature 32°F – 95°F (0°C – 35°C)
Dimensions (W x D x H) 13.7" x 10.4" x 3.5" (excluding protrusions)
Weight Approximately 7.9 lbs.
Approvals UL 60950-1 / cUL, FCC Part 15 subpart B class B
