| Display Technology |
Single 0.65” WXGA DLP® Technology by Texas Instruments |
| Native Resolution |
WXGA 1280 x 800 |
| Brightness1 (Bright Mode) |
5000 ANSI Lumens |
| Contrast |
15,000:1 |
| Lamp Life2 Eco+/Dynamic/Eco/Bright |
5000/4500/4000/3000 (hrs) |
| Throw Ratio 3 |
1.48 - 2.35, Offset: 96.2%~112.4% |
| Zoom Type |
1.5x Manual |
| Lens Shift |
+16.2% Vertical |
| I/O Connectors |
3xHDMI (1.4a 3D support) + MHL, VGA (YPbPr/RGB), Composite, 2 x Audio In 3.5mm, VGA out, Audio Out 3.5mm, RS232, RJ45, USB-A Power (1.5A), 3D-Sync, USB mouse/service |
| Speaker |
32 |
| Keystone Correction |
± 30° Vertical, ± 30° Horizontal |
| Weight (kg) |
4.6 |
| Dimensions (W x D x H) (mm) |
369 x 295 x 132 |
| Aspect Ratio |
16:10 Native, 16:9/4:3 Compatible |
| Offset |
96.2%~112.4% |
| Projection Screen Size |
0.68 – 7.65m (25.66” - 301.15”) Diagonal 16:10 |
| Projection Distance |
1.3 - 9.6m |
| Projection Lens |
F/2.5~3.26; f=20.91~32.63mm, 1.6x Manual Zoom |
| Uniformity |
85% |
| Computer Compatibility |
UXGA, SXGA+, HD, WXGA, XGA, SVGA |
| Video Compatibility |
PAL SECAM 576i/p, NTSC 480i/p, HD 720p/1080i/1080p |
| 3D Support |
Full 3D - The 3D features of Optoma projectors can only be used with compatible 3D content. Typical applications include use with 3D educational or 3D design and modelling systems. 3D TV broadcast systems, (SKY in the UK), Blu-ray 3D™ and 3D games from the Sony® PS3 or Microsoft® Xbox 360 are now supported as part of the HDMI v1.4a specification. |
| 3D Compatibility |
Side-by-Side:1080i50 / 60, 720p50 / 60
Frame-pack: 1080p24, 720p50 / 60
Over-Under: 1080p24, 720p50 / 60 |
| Horizontal Scan Rate |
15.375~91.146 KHz |
| Vertical Scan Rate |
24 ~ 85Hz (120Hz for 3D) |
| Displayable Colours |
1.07 Billion |
| Noise Level (Eco mode) |
30dB |
| Power Supply |
100-240V, 50-60Hz |
| Power Consumption |
365W Bright mode / 287W Eco+ mode (<0.5W Standby) |
| Lamp Type |
310W |
| Security |
Kensington Lock, Password Protection |
| On Screen Display |
19 Languages: English, German, French, Italian, Spanish, Portuguese, Polish, Dutch, Russian, Finnish, Swedish,Greek, Norwegian/Danish, Hungarian, Czech, Arabic, Turkish, Farsi, Romanian |
| Standard Accessories |
AC power cord, remote control, 2x AA batteries, quick start card, CD user manual |
| Optional Accessories |
Wireless 3D system, Wireless 3D glasses, DLP® Link™ 3D glasses, wireless, ceiling mount |
| Optional Wireless |
Yes |
| RoHS |
Compliant |
