| Power supply |
100 – 240 V AC, 50/60 Hz |
| Power consumption |
490 W (0.4 W with STANDBY MODE set to ECO,*1 11 W with STANDBY MODE set to NETWORK.) |
| LCD panel |
Panel size |
19.0 mm (0.75 inches) diagonal (16:10 aspect ratio) |
| Display method |
Transparent LCD panel (x 3, R/G/B) |
| Drive method |
Active matrix |
| Pixels |
1,024,000 (1,280 x 800) x 3, total of 3,072,000 pixels |
| Lens |
PT-EW630E |
Powered zoom (throw ratio 1.7–2.8:1), powered focus F 1.7–2.3, f 26.9–45.4 mm |
| PT-EW630EL |
Optional powered zoom/focus lenses and fixed-focus lens |
| Lamp |
330 W UHM lamp x 1, lamp replacement cycle: 4,000 hours*2 |
| Screen size (diagonal) |
1.02–10.16 m (40–400 inches) (16:10 aspect ratio) |
| Color reproducibility |
Full color (16,777,216 colors) |
| Brightness*3 |
5,500 lm (lamp power: Auto/Normal) |
| Center-to-corner uniformity ratio*3 |
0.9 |
| Contrast ratio*3 |
5,000:1 (full on/off, lamp power: Auto/Normal, iris: On) |
| Resolution |
1,280 x 800 pixels*4 |
| Scanning frequency |
HDMI/DVI-D |
(Horizontal) 26–80 kHz; (Vertical) 23–85 Hz; (Dot clock) 162 MHz or lower |
| RGB (analog) |
(Horizontal) 15–120 kHz; (Vertical) 48–100 Hz; (Dot clock) 230 MHz or lower (Signals exceeding the dot clock rate of 140 MHz are downsampled.) |
| YPBPR (YCBCR) |
fH: 15.75 kHz, fV: 60 Hz [480i (525i)] fH: 31.50 kHz, fV: 60 Hz [480p (525p)] fH: 45.00 kHz, fV: 60 Hz [720 (750)/60p] fH: 33.75 kHz, fV: 60 Hz [1035/60i] fH: 28.13 kHz, fV: 50 Hz [1080 (1125)/50i] fH: 28.13 kHz, fV: 50 Hz [1080/25sF] fH: 27.00 kHz, fV: 48 Hz [1080/24sF] fH: 33.75 kHz, fV: 60 Hz [1080/30sF] fH: 56.25 kHz, fV: 50 Hz [1080/50p] fH: 15.63 kHz, fV: 50 Hz [576i (625i)] fH: 31.25 kHz, fV: 50 Hz [576p (625p)] fH: 37.50 kHz, fV: 50 Hz [720 (750)/50p] fH: 33.75 kHz, fV: 60 Hz [1080 (1125)/60i] fH: 28.13 kHz, fV: 25 Hz [1080/25p] fH: 27.00 kHz, fV: 24 Hz [1080/24p] fH: 33.75 kHz, fV: 30 Hz [1080/30p] fH: 67.50 kHz, fV: 60 Hz [1080/60p] |
| Video/S-Video |
fH: 15.75 kHz, fV: 60 Hz [NTSC/NTSC4.43/PAL-M/PAL60], fH: 15.63 kHz, fV: 50 Hz [PAL/PAL-N/SECAM] |
| Optical axis shift*5 |
Vertical |
±60% from center of screen (powered) |
| Horizontal |
±10% from center of screen (powered) |
| Keystone correction range |
Horizontal: ±30°*6, vertical: ±40°*6 |
| Installation |
Ceiling/floor, front/rear |
| Built-in speaker |
3.7 cm round shape x 1, output power 10.0 W (monaural) |
| Terminals |
DVI-D IN (INPUT 1) |
DVI-D 24-pin x 1 (DVI 1.0 compliant, compatible with HDCP, compatible with single link only) |
| HDMI IN (INPUT 1) |
HDMI 19-pin x 1 (Deep Color, compatible with HDCP) |
| RGB IN (INPUT 1) |
D-sub HD 15-pin (female) x 1 (RGB x 1) |
| RGB 5BNC IN/ VIDEO IN (INPUT 2) |
BNC x 5 (RGB/YPBPR/YCBCR x 1), shared with VIDEO IN (BNC x 1) (composite video) |
| COMPONENT/ VIDEO IN (INPUT 3) |
RCA x 3 (YPBPR/YCBCR/composite video x 1) |
| S-VIDEO IN (INPUT 3) |
Mini DIN 4-pin x 1 |
| MONITOR OUT |
D-sub HD 15-pin (female) x 1 (RGB x 1) |
| AUDIO IN 1 |
M3 x 1 (L-R x 1) |
| AUDIO IN 2 |
M3 x 1 (L-R x 1) |
| AUDIO IN 3 |
RCA pin x 2 (L/R x 1) for VIDEO/S-VIDEO input |
| AUDIO OUT |
M3 x 1 (L-R x 1) for output (variable) |
| SERIAL IN |
D-sub 9-pin (female) x 1 for external control (RS-232C compliant) |
| REMOTE IN |
M3 Jack x 1 (for wired remote control) |
| LAN |
RJ-45 x 1 (for network connection, 100BASE-TX/10BASE-T, compliant with PJLink™ (class 1)) |
| Cabinet materials |
Molded plastic (PC + ABS) |
| Dimensions (W × H × D) |
PT-EW630E |
489.5 x 164*8 x 434 mm (19.3" x 6.5"*8 x 17.1") (with supplied lens) |
| PT-EW630EL |
489.5 x 164*8 x 370 mm (19.3" x 6.5"*8 x 14.6") (without lens) |
| Weight*7 |
PT-EW630E |
Approximately 10.3 kg (22.7 lbs) (with supplied lens) |
| PT-EW630EL |
Approximately 9.6 kg (21.2 lbs) (with supplied lens) |
| Noise level*7 |
37 dB (Lamp power: Normal); 31 dB (Lamp power: Eco1 or Eco2) |
| Operating temperature |
0°C–40°C (32°F–104°F)*9 |
| Operating humidity |
20% - 80% (no condensation) |
| Supplied accessories |
Power cord x 1 ( x 2 for PT-EZ570E/EZ570EL, PT-EW630/EW630EL, PT-EX600E/EX600EL), power cord holder/power cord cover x 1, wireless/wired remote control unit x 1, batteries (AAA/R03/LR03 type x 2), computer cable (1.8 m, for VGA) x 1, Software CD-ROM (Logo Transfer Software, Multi Projector Monitoring & Control Software) x1, |
