מטריצת Kramer FC-132ETH עם מגוון כניסות ויציאות (ראה תאור קצר)

PORTS

• 1 RS–232/RS–485 selectable and 32 RS–232 serial output ports on 3–pin terminal blocks, 8 RS–232 serial input ports on 3–pin terminal blocks, 1 RS–232 serial control port on a 3–pin terminal block, 1 Ethernet on an RJ–45 connector, 1 mini USB connector for local services

SUPPORTED SERIAL PORT BAUD RATES

• 1200, 2400, 4800, 9600, 19200, 38400, 57600, 15200bps

RS-232 COMMUNICATION

• Transparent up to 115200bps

MAXIMUM DATA HANDLING OF DEVICE

• Up to 310kbps summed on all ports

CONTROLS

• Serial Select button, RS–485 terminator switch, DHCP and Factory Default buttons. Front panel buttons and LCD display, RS–232, Ethernet

INDICATORS

• Power, Ethernet, Serial I/O, and DHCP status LEDs

POWER CONSUMPTION

• 100–240V AC, 50/60Hz, 17VA

OPERATING TEMPERATURE

• 0° to +40°C (32° to 104°F)

STORAGE TEMPERATURE

• –40° to +70°C (–40° to 158°F)

HUMIDITY

• 10% to 90%, RHL non–condensing

COOLING

• Convection

ENCLOSURE TYPE

• Aluminum

VIBRATION

• ISTA 1A in carton (International Safe Transit Association)

SAFETY REGULATORY COMPLIANCE

• CE

ENVIRONMENTAL REGULATORY COMPLIANCE

• Complies with appropriate requirements of RoHs and WEEE

INCLUDED ACCESSORIES

• Power cord, rack mounting brackets

OPTIONAL

• Serial cables: C–D9F/OPEN–3/6/10/15/25/35/50, BC–1T–300M bulk cable

PRODUCT DIMENSION

• 19" x 7.20 x 1U (43.6cm x 18.30cm 4.36cm) W, D, H

PRODUCT WEIGHT

• 1.7kg (3.7lbs) approx

SHIPPING DIMENSION

• 55.00cm x 27.60cm x 10.70cm (21.65" x 10.87" x 4.21" ) W, D, H

SHIPPING WEIGHT

• 2.5kg (5.5lbs) approx
