ממיר כניסות 9 ליציאה 3 Kramer VP-796 SCALER

INPUTS

• 1 HDBT on an RJ–45 connector, 1 DisplayPort connector, 2 HDMI (4K UHD) connectors, 1 HDMI (HD) connector, 1 DVI–U (DVI/HDMI & VGA/RGBS/YPbPr), 1 VGA on a 15–pin HD connector, 1 CV on an BMC connector

OUTPUTS

• 1 HDBT on an RJ–45 connector, 1 HDMI connector, 1 DVI/HDMI on a DVI–I connector, 1 S/PDIF on an RCA connector

PORTS

• 1 RS–232 on a 9–pin D–sub connector, 1 LAN on an RJ–45 connector, 2 USB–A connectors

COMPONENT VIDEO INPUT FORMATS

• 484i (480i) and 576i (SD), 480p, 576p (ED), 720p, 1080i @50, 59.94 and 60Hz and 1080p @23.98, 24, 25, 29.97 and 30Hz

HDMI/DVI SIGNAL FORMATS

• 1280x72
• 1920x101010
• 2048x10
• 3840x21
• 4096x21

OUTPUT RESOLUTIONS

• 640x48
• 800x60
• 1024x76
• 1280x768010
• 1400x10
• 1600x12
• 1920x12
• 2024x10
• 2560x101416
• 3860x21
• 4096x21

FRAME RATE

• 60Hz, 59.94Hz, 50Hz, 48Hz, 25Hz, 24Hz, 23.97Hz, auto

OPERATING TEMPERATURE

• 0° to +40°C (32° to 104°F)

STORAGE TEMPERATURE

• –40° to +70°C (–40° to 158°F)

HUMIDITY

• 10% to 90%, RHL non–condensing

POWER CONSUMPTION

• 100–264V AC, 50/60Hz

STANDARDS COMPLIANCE

• CE: 2004/108/EC Electromagnetic Compatibility Directive, and 2006/95/EC Low Voltage Directive. Compliance is to EN55022 Class A

INCLUDED ACCESSORIES

• Power cord, Rack “ears”

PRODUCT DIMENSION

• 19" x 7.20 x 1U (43.6cm x 18.30cm 4.36cm) W, D, H

PRODUCT WEIGHT

• 2.7kg (6.0lbs) approx

SHIPPING DIMENSION

• 0.00cm x 0.00cm x 0.00cm (0.00" x 0.00" x 0.00" ) W, D, H

SHIPPING WEIGHT

• 3.8kg (8.3lbs) approx
