ממיר תמונה Kramer WP-572 עם כניסה DGKat ויציאה HDMI

יצרן: Kramer,
HDMI HDCP 2.2 Wall–plate Receiver over Long–Reach DGKat (EU, UK, US–D),
Requires Shielded Twisted Pair Cable,
Max. Data Rate — 4.95Gbps (1.65Gbps per graphic channel),
Size — Wall Plate — 1 gang US,
Audio — E,

שימוש:
Board, conference, and training rooms,
Presentation systems,
Signal distribution and home theater.

מאפיינים ושידרוגים:

פרטים נוספים:

אחריות: 12 חודשים
זמן אספקה: עד14ימי עסקים
דגם: KRAMER WP-572

מחיר ₪ 767 ILS 9/7/2027 In stock KRAMER ELECTRONICS KRAMER WP-572 KRAMER WP-572

קנה עכשיו הוסף לסל

תיאור מלא
מפרט טכני
חוות דעת

Max. Data Rate — 4.95Gbps (1.65Gbps per graphic channel).
HDTV Compatible.
HDCP Compliant.
DGKat™ Signal Integration — Kramer’s unique technology for converting TMDS as well as control and communication to signals that run over twisted pair cables. We strongly recommend using Kramer DGKat™ cables designed specifically for optimum performance.
HDMI Support — x.v.Color™, up to 7.1 Uncompressed Audio Channels.
3D Pass–Through.
System Range — Up to 90m (295ft) at 1080i, or up to 30m (98ft) at 1080p on shielded BC–DGKat524 cable. Up to 90m (295ft) at 1080i, or up to 70m (230ft) at 1080p on shielded BC–DGKat623 cable. Up to 100m (330ft) at 1080i or up to 90m (295ft) at 1080p on shielded BC–DGKat7a23 cable.
Cable — Requires shielded twisted pair (STP) cable. For optimum range and performance use, use Kramer's BC–DGKat524, BC–DGKat623 and BC–DGKat7a23 cables. Note that the transmission range depends on the signal resolution, graphics card and display used. The distance using non–Kramer CAT 5, CAT 6, and CAT 7 cables may not reach these ranges. Use only shielded cable where both ends of the shield are soldered to ground.
EDID PassThru — Passes EDID signals between the source and display.
ON LED — Lights red when receiving power only, orange when either input or output and power are attached, and green when both an active input and output are attached.

סוג מוצר :	מתאמים ממירים Scalers
סוגי כניסות\יציאות:	HDMI, DGkat
מס כניסות :	1 כניסות
מס יציאות :	1 יציאה
יצרן:	Kramer
טווח מחירים:	מ - 501 ₪ - עד 1000 ₪
