מקרן אינטראקטיבי Maxell MC-TW3006 3300L WXGA 1280x800 Ultra-Short Throw Interactive

Optical

Panel Size 3LCD 15mm (0.59")

Panel Structure 3LCD

Resolution WXGA (1280 x 800)

Light Output (Brightness) ANSI Lumens 3300 (Normal), 2706 (Eco), 2244 (Eco-2)

Contrast Ratio 10,000:1

Lamp Life (Hours) 4000 (Normal), 5000 (Eco), 6000 (Eco-2)

Lens Built-in

Lens Zoom Digital Zoom x 1.35

Lens Focus Powered Focus

Focus Distance 0.409 – 0.689m

Distance to Width Ratio/ Throw Ratio (:1)  0.3

Diagonal Display Size 60-100"

Digital Keystone Correction Horizontal ±5°, Vertical ±5°

Features

Speakers 16w Mono

Connections

Digital Input HDMI x 2

Analogue Input 15 pin Mini D-Sub x 2, RCA Jack x 1

Video Output 15 pin Mini D-Sub x 1

Audio Input 3.5mm Stereo Mini Jack x 1, RCA Jack (L/R) x 1

Audio Output 3.5mm Stereo Mini Jack x 1

RS-232C Control 1 x 9-pin D-Sub

Wireless LAN USB-WL-11N wireless adaptor (optional)

Wired LAN Yes

USB Type A Used for PC-less presentation, wireless network or optional wireless pen tablet TB-1

USB Type B USB Type B x1 (Interactive function, USB display, or USB mouse control)

Power

Power Supply AC 100V-120V / AC 220V-240V (50/60Hz)

Operating Power Consumption 360W

Standby Power Consumption Less than 0.35W

Physical

Weight 4.3kg

Dimensions (WxHxD) 377 x 136 x 360mm

Noise 36dB (Normal), 32dB (Eco), 28dB (Eco-2)

Filter Life (Hours) 4000

Compatibility

Computer

IBM Compatible VGA, SVGA, XGA, WXGA/WXGA+/SXGA/SXGA+/UXGA (compressed), MAC16"

Video 525i (480i), 525p (480p), 625i (576i), 1125i (1080i@50/60), 750p (720p@50/60), 1125p (1080p@50/60)

Accessories

Supplied Accessories Power Cable (4.5m) x1, Computer Cable (5.0m) x1, USB Cable (5m) x1, Interactive Pen x2, Pen Tip x4, AAA Batteries x4, IR Remote Control Unit x1, AA Batteries x2, Cable Cover x1, Application CD (for network, etc.) x1, Application DVD (for interactive) x1, CD User Manual x1, Concise User Manual x1, Adapter Cover x1

Optional Accessories USB wireless adaptor USB-WL-11N, Wall mount unit: HAS-WM03, HAS-WM05 (Low ceiling wall mount), TT-03 Table Top Kit, HAS-WB01 (XGA mount adaptor) HAS-WB02 WXGA mount adaptor

Remote Control HL03033

Replacement Lamp / Filter DT01411 / UX37191 (Hybrid)
