î÷øï Maxell MC-X8801 8000L XGA 1024x768

Panel Size 3LCD 20mm (0.79")

Resolution XGA (1024x768)

Light Output (Brightness) ANSI Lumens 8000 (Normal), 6400 (Eco)

Contrast Ratio 10,000:1

Lamp Life (Hours) 2000 (Normal), 4000 (Eco)

Lens Interchangeable, not included

Lens Zoom Powered Zoom x 1.7

Lens Focus Powered Focus

Throw Distance 1.1 – 37.6m (ML-713)

Distance to Width Ratio/ Throw Ratio (:1) 1.7 (Wide), 2.9 (Tele) (ML-713)

Diagonal Display Size 30 – 600"

Features

Speakers 8W Stereo

Digital Keystone Correction Horizontal ±37.5°, Vertical ±37.5° (ML-713)

Connections

Digital Input HDMI x 2, HDBaseT x 1, DisplayPort x 1

Analogue Input 15 pin Mini D-Sub x 1, RCA Jack x1

Video Output 15 pin Mini D-Sub x 1

Audio Input 3.5mm Stereo Mini Jack x 1, RCA Jack (L/R) x 1

Audio Output RCA Jack (L/R) x 1

RS-232C Control 1 x 9-pin D-Sub

Wireless LAN USB-WL-11N wireless adaptor (optional)

Wired LAN RJ45 Connector x 1

USB Type A USB Type A x 1 (wireless adapter)

USB Type B No

Power

Power Supply AC 100V – 120V / AC 220V – 240V (50/60Hz)

Operating Power Consumption 560W

Standby Power Consumption Less than 0.35W

Physical

Weight 11.1kg

Dimensions (W x H x D) (Without feet) 498 x 156 x 426mm

Noise 40dB (Normal), 33dB (Eco)

Filter Life (Hours) 20,000

Compatibility

Computer IBM Compatible VGA, SVGA, XGA, WXGA/WXGA+/SXGA/SXGA+/UXGA (compressed), MAC16"

Video 525i (480i), 525p (480p), 625i (576i), 1125i (1080i@50/60), 750p (720p@50/60), 1125p (1080p@50/60)

Accessories

Supplied Accessories Power Cable (1.8m) x1, Computer Cable (2m) x1, IR Remote Control Unit x1, AA Batteries x2, Application CD (for network, etc.) x1, CD User Manual x1, Concise User Manual x1, Security Label x1, Lens Hole Cover x1, Adapter Cover x1, Terminal Cover x1, HDMI Cable Holder x2, Cable Tie x2

Optional Accessories  USB wireless adaptor USB-WL-11N. Wireless pen tablet TB-1 is optional.

Remote Control HL02805

Replacement Lamp / Filter DT01881
