מקרן נייד/קבוע משרדי - ביתי SONY VPL EX276 XGA 3700 Lumens

Display system 3 LCD system
Display device
Size of effective display area 0.63” (16.0 mm)
Number of pixels XGA (1024 x 768)
Aspect ratio 4:3
Projection lens
Focus Manual
Zoom > Powered / Manual Manual
Zoom > Ratio Approx. 1.6 x
Throw ratio 1.40:1 to 2.27:1
Light source
Type *1 lamp
Wattage 210 W type
Recommended　lamp replacement time*2
Lamp mode: High 3000 H
Lamp mode: Standard 5000 H
Lamp mode: Low 7000 H
Filter cleaning / replacement cycle*2 (Max.)
Filter cleaning / replacement cycle*2 (Max.) 7000 H*3 (cleaning)
Screen size
Screen size 30” to 300”
(0.76 m to 7.62 m)
Light output
Lamp mode: High 3700 lm
Lamp mode: Standard 2700 lm*4
Lamp mode: Low 2100 lm*4
Color light output
Lamp mode: High 3700 lm
Lamp mode: Standard 2700 lm*4
Lamp mode: Low 2100 lm*4
Contrast ratio (full white / full black)*5
Contrast ratio (full white / full black)*5 3000:1
Input
Composite video > Pin Jack 1
S video > Mini DIN 4-pin 1
Computer > Mini D-sub 15-pin 2
HDMI (HDCP) 1
Audio > Pin Jack (L/R) 1
Audio > Stereo mini jack 2
Output
Monitor > Mini D-sub 15-pin 1*6
Audio*7 > Stereo mini jack 1
I/O, Control, Others
RS-232C > D-sub 9-pin 1 (male)
LAN > RJ-45, 10BASE-T/100BASE-TX 1
USB > Type A 1
USB > Type B 1
Microphone input > Mini jack 1
Wireless IFU-WLM3(Option)*8
Speaker
Speaker 16 W x 1 (monaural)
Keystone correction (Max.)*9
Vertical +/- 30°
Power requirements
Power requirements AC 100 V to 240 V
3.1 A to 1.3 A, 50/60 Hz
Power consumption
AC 100 V to 120 V > Lamp mode: High 306 W
AC 100 V to 120 V > Lamp mode: Standard 256 W*4
AC 100 V to 120 V > Lamp mode: Low 226 W*4
AC 220 V to 240 V > Lamp mode: High 298 W
AC 220 V to 240 V > Lamp mode: Standard 249 W*4
AC 220 V to 240 V > Lamp mode: Low 220 W*4
Standby mode power consumption
AC 100 V to 120 V > Standard 5.9 W
AC 100 V to 120 V > Low 0.5 W
AC 220 V to 240 V > Standard 5.9 W
AC 220 V to 240 V > Low 0.5.W
Heat dissipation
AC 100 V to 120 V 1044 BTU
AC 220 V to 240 V 1017 BTU
Dimensions (W x H x D) (without protrusions)
Dimensions (W x H x D) (without protrusions) 365 x 96.2 x 252 mm
14 3/8 x 3 25/32 x 9 29/32 in
Mass
Mass 4 kg / 8 lb 11 oz
Supplied accessories
Remote commander RM-PJ8
Optional accessories
Replacement lamp LMP-E212
Wireless LAN Module IFU-WLM3
